Steam Activated Powder Particle Sintering Atmosphere Rotary Furnace Is Suitable for Industrial and Mining Enterprises and Research Institutes
Product Name:Steam activated powder particle sintering atmosphere rotary furnace is suitable for industrial and mining e
|Furnace Liner Size||Ø219X400mm(Diameter X Length)|
|Transport Package||Wooden Box|
Product DescriptionProduct Name:Steam activated powder particle sintering atmosphere rotary furnace is suitable for industrial and mining enterprises and research institutes1. Product description
(1) SummaryAtmosphere rotary furnace, mainly suitable for dynamic sintering of dust and particles, to make materials more evenly heated, shorten sintering time, and consume energy Advantages of reduced cost and higher quality.(2) Electric furnace construction2.1 The furnace shell is welded with steel plates and profiles, and is equipped with a detachable protective plate. The protective plate is electrostatically sprayed, which is aesthetically pleasing. The main color is industrial gray and light yellow.2.2 This furnace is of a split structure, and the upper half can be opened to facilitate the removal of the furnace liner for maintenance or to accelerate the cooling time.2.3 The furnace liner is made of 310S stainless steel material, and the furnace hall is of a large belly shape. The large belly shape can fix the material in the constant temperature zone and rotate for sintering, without causing the material to run into the low temperature zone.2.4 The insulation structure adopts alumina ceramic fiber board to prevent heat leakage. Ceramic fiber board can accelerate the heating of the electric furnace, achieve more significant insulation effect, and achieve energy-saving.
2. Product parameters
|Rated power||≈8KW (actual power is automatically controlled and adjusted by the instrument)|
|Control accuracy||±1ºC(Under constant temperature state)|
|Furnace liner size||Ø219x400mm(Diameter X Length)|
|Furnace liner material||SUS310S stainless steel|
|Alarm protection||Overtemperature and couple breaking alarm protection|
|Use Atmosphere||Inert gases such as water vapor and nitrogen|
|Usage method||Injecting atmosphere to protect sintering|
|Lifting angle||0-20degrees (Electrically adjustable)|
|Heating element||Resistance wire|
|Feed system||Manual feeding|
|Main color of appearance||Industrial gray, light yellow|
|Overall material of furnace shell||A3 steel|
3. Detailed photos
4. Technical document provision
|1||Electric furnace manual||One copy|
|2||Electrical schematic diagram||One copy|
|3||Instrument manual||One set|
|4||Electric furnace shipping list||One copy|
5.Company profileYixing Bangshida Furnace Industry Co., Ltd. has been specializing in the production of experimental electric furnaces, industrial electric furnaces, and their components since 2013.Our products are widely used in electronic components, powders, ceramics, lithium batteries, new energy, new materials, and other occasions and fields.Our products are reliable and durable, and have many years of experience to support them.21%-30%of our products are exported to all parts of the world.By leveraging our hard-won reputation, honesty, reliability, and quality, Yixing Bangshida Furnace Industry Co., Ltd. aims to continue to be a sales pioneer.At the same time, we are looking for global partners overseas. If your company is an end user, distributor, or agent of experimental and industrial electric furnaces, please contact us.6.Our Customers (Partial)Shanxi Coal Research Institute, Chinese Academy of SciencesBeijing Low Carbon Clean Energy Research InstituteHenan Provincial Academy of Sciences, ChinaXiamen Rare Earth Materials Research InstituteFujian Institute of Chinese Academy of SciencesBeijing General Research Institute of Mechanical ScienceChina General Technology Research InstituteGuangdong Petrochemical Research InstituteShanghai Research Institute of the Chinese Academy of SciencesBeijing Non ferrous Metals Research InstituteShanghai Institute of MaterialsZhangjiagang New Energy Materials Research InstituteXiamen Research Institute, Chinese Academy of SciencesBeijing Institute of Microchemistry…
7. Patent certificate8. After sales service(1) Within a year, we will provide technical support. During the warranty period, there are quality issues that require free repair. If vulnerable parts and other accessories need to be replaced after the warranty period, the required fees will be paid.(2) We can provide remote video guidance for any technical issues.(3) We will promptly address any issues within 24 hours.9. FAQQ: Are you a factory or a trading company?
A: We are a factory with 10 years of professional technical experience, specializing in laboratory and industrial heat treatment furnace manufacturers, integrating design, manufacturing, and sales
Q: How do I order?
A: Inquiry from us → Use scenario notification → Receive our proposal recommendation → Negotiate details → Confirm the proposal → Sign a contract/deposit → Place an order for production → Goods are ready → Deliver → Further cooperation
Q: Which mode of transportation is available?
A: It is a sea express, China express, and other modes of transportation are available. Please contact us
Q: How long will it take to deliver [produce] and ship?
A: The delivery time depends on the quantity you ordered. It usually takes 30-60 working days
Q: My package is missing some products. What can I do?
A: Please contact our support team, we will use the packaging to confirm your order content, and compensate for shipping based on the actual situation. We apologize for the inconvenience caused to you
Q: How do I confirm payment?
A: We accept payment by wire transfer. Please contact us before you make payment through another payment method. An additional 30-40% deposit is feasible, and the balance should be paid before shipment.We look forward to working with you in the near future!
